Potting & Molding system
Insulation material (Flame retardancy)
The flame retardant molding material is the HTF-series product. It is an eco-friendly flame retardant product that does not contain RoHS regulated harmful substances. It is used as a flame retardant molding material for electrical and electronic parts that require flame retardancy. In particular, the HTF-1500 product is a UL approved product and has excellent flame retardancy.
| Product Name | Mix Ratio | Viscosity(cps,25℃) | Tg(℃) | Curing condition | Application |
|---|---|---|---|---|---|
| HTF-1500-1 | 100 : 20 |
3,000~5,000 40~80 |
70~80 |
25℃x (1~2)day or 60℃x (3~4)h |
UL Approval(UL File No. E240028) UL94, V-0 grade |
| HTF-1500-2 | 100 : 100 |
5,000~15,000(60℃) 25,000~45,000(60℃) |
85~95(Tg) | 120℃x 12h | UL Approval(UL File No. E240028) UL94, V-0 grade |
| HTF-1500-3 | 100 : 10 | 15,000 ~ 30,000 (25℃) 10 ~ 40 (25℃) |
80 ~ 90 | 25℃ x 24h or 60℃ x 2h | UL approved product (UL File No. E240028) UL94, V-0 Room temperature curing Epoxy |
| HTF-1600 |
100 : 20 |
5,000~9,000 200~400 |
50~60 |
25℃x 1day or 60℃x 2h |
UL94, V-1 grade High thermal shock resistance |
| HTF-2500 |
100 : 30 |
30,000~50,000 50~150 |
85~90 |
(90℃x2h)+(120℃x 4h) |
UL94, V-0 grade, Hot cure Type High thermal resistance |
| HTS-2600 | 100 : 100 |
15,000~18,000 13,000~15,000 |
85-90 | (90℃x2h)+(120℃x 4h) | UL94, V-0 grade High electrical properties |
| HTS-2700 | 100 : 20 | 25,000~18,000 50~80 |
85-90 | (90℃x2h)+(120℃x 4h) | UL94, V-0 grade High electrical properties |
